A street sweeper machine is a battery-powered cleaning vehicle that sweeps, vacuums, and collects debris from outdoor and large indoor surfaces. It combines a main brush, side brushes, a water spray system, and a vacuum dust control system into one compact unit. The YG series small road sweeper offers four models with sweeping widths from 1260mm to 2100mm and working capacities from 6500m²/h to 18500m²/h. Each model suits different site sizes and cleaning requirements, from narrow sidewalks to large industrial parks.
Street Sweeper Machine Technical Specifications:
| Model | YG-1 | YG-2 | YG-3 | YG-4 |
| Sweeping width(mm) | 1260 | 1400 | 2000 | 2100 |
| Main brush width(mm) | 500 | 700 | 700 | 800 |
| Working capacity(m2/h) | 6500 | 8500 | 16500 | 18500 |
| Trash can capacity(L) | 80 | 120 | 180 | 220 |
| Water tank(L) | 30 | 130 | 100 | 100 |
| Side brush width(mm) | 450 | 500 | 500 | 500 |
| Working speed(km/h) | 8 | 8 | 12 | 15 |
| Working time(h) | 6-8 | 3-4 | 4-5 | 6-8 |
| Charging time(H) | 5-6 | 3 | 4 | 5-6 |
| Net weight(kgs) | 380 | 480 | 870 | 950 |
| Battery | 48V 52Ah | 48V 58Ah | 48V 100Ah | 48V 150Ah |
| Dimension(mm) | 1500*1160*1200 | 1600*1400*1250 | 2250*1900*1900 | 2400*2050*1950 |
7 Features That Make the YG Street Sweeper Machine Stand Out
The YG series street sweeper machine builds on practical features that reduce labor, improve cleaning quality, and extend machine life. Each feature addresses a real challenge in large-area cleaning.
- Intelligent operation panel. The operation panel uses clear icons and a simple layout. New operators learn the controls within minutes. The panel shows battery voltage, brush status, and water level. This transparency helps operators avoid mistakes and plan their work.
- Brand motor and controller. The motor delivers stable performance and high speed-control precision. The controller provides strong power and reliable climbing ability. The street cleaner machine handles slopes up to 25 degrees. This matters when cleaning ramps, loading docks, or uneven outdoor surfaces.
- Cold-rolled steel chassis and rotomolded body. The chassis uses cold-rolled steel formed in one piece. This construction resists bending and vibration. The body uses thick rotomolded polyethylene that withstands high temperatures and corrosion. The machine keeps its shape and appearance even after years of outdoor use.
- Wear-resistant main and side brushes. The main brush and side brushes use wear-resistant bristles. The bristles do not break or fall out during normal operation. Brush replacement frequency depends on use—typically every 5 to 8 months. This durability reduces maintenance interruptions.
- Brand battery with long service life. The small road sweeper uses maintenance-free batteries from trusted brands. Battery service life reaches up to 8 years. The battery pack provides 48V power with capacities from 52Ah to 150Ah depending on the model. Charging takes 3 to 6 hours. Working time ranges from 3 to 8 hours per charge.
- Disc brake system for safety. The disc brake system prevents side slipping and deviation. This feature protects operators on wet or sloped surfaces. The machine stops reliably when needed.
- Vacuum dust control core. The vacuum dust control core captures fine particles during sweeping. The system suppresses dust and keeps the air clean. This feature makes the machine suitable for hospitals, schools, and food processing facilities where dust control matters. A street cleaner machine with a strong vacuum core leaves a cleaner surface than a broom-only unit.
Operating Notes for the Street Sweeper Machine
Proper operation extends machine life and improves cleaning results. Follow these seven rules when using the machine.
Rule 1: Turn the key twice. Insert the key and turn it twice. The first turn powers the control system. The second turn starts the machine. This two-step process protects the electrical system from power surges.
Rule 2: Handle large debris with the pedal. When you encounter large items, step on the large port pedal intermittently. This action opens a wider intake path. The main brush and vacuum system then pull the debris into the trash can. Do not force large items through the standard intake.
Rule 3: Open water before pressing spray. Always open the water supply valve before pressing the spray button. This sequence prevents air from entering the water lines. If you press the spray button first, the pump may run dry and damage the seals.
Rule 4: Run the dust removal cycle after work. After completing your cleaning session, activate the dust removal cycle. This function shakes dust from the filter and into the collection bin. It keeps the vacuum system working at full efficiency.
Rule 5: Do not work in rain. Water enters the electrical system and causes short circuits. If you must work in damp conditions, wait until the rain stops and the ground dries. This rule applies to every small road sweeper, not just the larger models.
Rule 6: Clean the filter with air, not water. Clean the filter with compressed air. Do not use water. Water damages the filter media and reduces dust control performance. Use an air pump to blow dust out of the filter pleats. Clean the filter regularly—after every 20-30 hours of operation.
Rule 7: Watch the voltage display. The display shows battery voltage, not a percentage. As the battery discharges, voltage drops. When voltage falls below the recommended level, stop working and charge the battery. Do not wait until the machine loses power completely. Deep discharges shorten battery life.
6 FAQs About the Street Sweeper Machine
A:The YG-4 covers 18500m²/h. It sweeps a 2100mm path at 15km/h.
A: One street sweeper machine replaces 8 to 12 cleaning workers. The cleaning efficiency is 10 times that of manual sweeping.
A: Yes. It climbs slopes up to 25 degrees.
A: Working time ranges from 3 to 8 hours depending on the model. The YG-1 and YG-4 provide 6-8 hours. The YG-2 provides 3-4 hours. The YG-3 provides 4-5 hours.
A: Check the brushes for wear. Clean the filter with compressed air. Check the water tank level. Monitor battery voltage. Perform the post-work dust removal cycle.
A: The road sweeper machine price depends on the model and configuration. The YG-1 is the most economical. The YG-4 offers the highest capacity and longest working time. Contact YG for a specific quotation based on your requirements.
