A concrete laser screed machine, also known as a concrete screed, is an automated construction device specifically designed for precise leveling, slurry lifting, and compaction of concrete surfaces and roads after pouring. Its core function is to eliminate unevenness and inconsistent thickness on the concrete surface, ensuring the poured surface achieves the designed flatness and density.
Compared to traditional manual leveling using screeds and vibrators, the concrete laser screed machine completely solves the pain points of large errors, low efficiency, and high labor intensity associated with manual operation, making it a key piece of equipment for the large-scale and standardized development of modern concrete construction. If you are interested in our machines, please contact us immediately.
Concrete Laser Screed Machine Technical Parameter
| Model | YGJX31 | YGJX32 | YGJX33 | YGJX34 |
| Engine | ||||
| Model | Generator set | GX390 Electric start | GX390 Electric start | GX390 Electric start |
| Power | 2.0kW | 13hp/3600rpm | 13hp/3600rpm | 13hp/3600rpm |
| Fuel tank (L) | 14.5 | 6.5 | 6.5 | 6.5 |
| Running device | ||||
| Drive | Motor | Hydraulic motor | Hydraulic motor | Hydraulic motor |
| Running mode | Infinitely variable speed | Handle control, stepless speed | Handle control, stepless speed | Handle control, stepless speed |
| Running speed(m/min) | 0-36 | 0-45 | 0-65 | 0-45 |
| Suggest working speed(m/min) | 5 | 5 | 5 | 5 |
| Screed head | ||||
| Type | Self-leveling | Electric control, self-leveling | Self-leveling | Hydraulic control, self-leveling |
| Width | 2500mm | 2500mm | 2500mm | 2500mm |
| Exciting force | 500N | 500N | 500N | 500N |
| Vibration frequency | 50Hz | 50Hz | 50Hz | 50Hz |
| Laser control system | ||||
| Control type | Microcomputer laser scan | Microcomputer laser scan | Microcomputer laser scan | Microcomputer control |
| Operation mode | Walk-behind | Walk-behind | Walk-behind | Walk-behind |
| Forward and reverse | Handgrip control, stepless speed-walking | Hydraulic control | Handgrip control, stepless speed-walking | Hydraulic control |
| Size and weight | ||||
| Working size(mm) | 2758*2622*1980 | 2740×2659×1980 | 2578×2643×1980 | 2780*2622*1980 |
| Weight(kg) | 295 | 365 | 380 | 410 |
Main Types of Concrete Leveling Machines
- Laser Concrete Leveling Machine: Utilizing laser positioning, it achieves a leveling accuracy of ±2-3mm. Suitable for industrial plants, logistics warehouses, and other scenarios requiring high flatness. Available in ride-on and walk-behind models, it is one of the most accurate models on the market.
- Concrete Surface Leveling Machine: Focused on surface construction, it features an optimized walking mechanism, adaptable to various indoor and outdoor surface scenarios. Easy to operate and cost-effective, it is suitable for routine leveling needs in small and medium-sized buildings and residential garages.
- Automatic Concrete Leveling Machine: Equipped with an intelligent control system, it can achieve preset parameters, automatic walking, and unattended operation, significantly reducing manual intervention. Suitable for large-scale construction and effectively improving work consistency.
Core Advantages of Concrete Laser Screed Machine
1. High Precision and Controllable Quality
Concrete laser screed machines optimize benchmark positioning for floor construction, ensuring seamless construction over large areas and improving the overall aesthetics and durability of the floor.
2. High Efficiency and Energy Saving, Reduced Costs
The equipment achieves integrated operation, requiring only one operator. Its construction efficiency is 3-5 times that of manual labor, completing 2000-5000㎡ of work per day, significantly shortening the construction period. Furthermore, the equipment has low energy consumption and reduces concrete waste, further lowering the overall construction cost.
3. Convenient Operation and Strong Adaptability
The equipment adopts an intelligent control design, making operation simple and easy to understand. No professional technicians are required; simple training is sufficient to operate it. Automatic concrete leveling machines have intelligent control functions, allowing for preset parameters and automatic movement, reducing operational difficulty. Simultaneously, the equipment is adaptable to various scenarios, including indoor garages, industrial plants, municipal roads, and airport runways.
4. Durable, easy to maintain, and excellent cost-performance ratio
Core components are made of high-strength steel and wear-resistant parts, which can withstand the harsh environment of the construction site and have a long service life. The equipment has a simple structure, and daily maintenance only requires periodic inspection of key components such as the hydraulic system and laser sensors, resulting in low maintenance costs, reduced equipment downtime, and guaranteed construction progress.
Frequently Asked Questions about Concrete Laser Screed Machine
1. What parameters should I focus on when purchasing a concrete laser screed machine?
A: Focus on three key points: laser positioning accuracy (recommended ≥±2mm), engine power (determines work efficiency), and vibrating plate width (affects daily construction area). Also, pay attention to the brand and warranty period of accessories to ensure long-term stable use.
2. What should I do if my automatic concrete leveling machine jams and cannot operate normally?
A: First, turn off the power. Check the chains and rollers of the walking mechanism for obstructions. Clean them and apply lubricant. If the jamming persists, check the hydraulic system for sufficient hydraulic oil and leaks. Replenish hydraulic oil and repair any leaks. Additionally, check the control system parameters to ensure the walking speed is set correctly to avoid jamming due to abnormal parameters.
3. What causes sanding and cracks to appear on the concrete floor after using a concrete leveling machine?
A: There are two main reasons: First, the concrete mix ratio is unreasonable, with an excessively high water-cement ratio. The concrete mix ratio needs to be adjusted to control the slump within a reasonable range. Second, the equipment vibration frequency is insufficient, failing to properly compact the concrete. Vibration parameters can be adjusted to improve the efficiency of the high-frequency vibrator, ensuring sufficient concrete slurry and achieving the required density. Simultaneously, proper ground curing should be carried out promptly after operation to prevent rapid moisture evaporation, which can lead to sanding and cracking.
4. Are spare parts for the YG concrete laser screed machine easy to replace?
A: Yes, YG has a stock of core spare parts. Consumable parts such as laser sensors and hydraulic components can be quickly replenished without affecting the construction progress.
5. Is there operational training after purchase?
A: Yes, after purchasing a YG concrete laser screed machine, the manufacturer will provide free operational training, teaching operators how to use the equipment, perform daily maintenance, and troubleshoot simple malfunctions, ensuring quick mastery.
Prioritize YG Manufacturer
The key to purchasing a concrete laser screed machine is, first and foremost, selecting the appropriate model based on the construction area, required flatness, and budget. For small, low-standard projects, a standard concrete screed is suitable; for mid- to high-end projects, laser concrete screeds and automatic concrete screeds are preferred. Secondly, the manufacturer’s strength directly determines the equipment’s quality and after-sales service. Prioritize brands with large production bases, comprehensive after-sales service networks, and quality certifications. We recommend YG.
As a professional concrete laser screed machine, YG boasts a standardized production base. Its products undergo rigorous quality testing, with core components all imported. It offers a 1-year warranty, 48-hour after-sales response, and technical training. Its best-selling models cover various application scenarios, ensuring suitable machines for both small, medium, and large projects. YG is definitely your ideal choice. Contact us now!
