An industrial scrap shredder is a heavy-duty size reduction system built to handle a wide spectrum of industrial waste materials in a single unit. Unlike dedicated single-material crushers that only work for specific waste types, this equipment processes scrap steel, waste tires, electronic waste, hard plastic, wooden pallets, industrial packaging barrels and thick rubber products with consistent performance. It serves as a versatile scrap metal shredder machine for recycling yards and industrial facilities that deal with mixed waste streams, eliminating the need to deploy multiple dedicated crushing units for different material categories. The dual-shaft shredder design forms the core of its multi-material adaptability, using interlocking shear action to break down both soft flexible waste and hard rigid scrap without frequent part replacement.
Industrial Scrap Shredder Technical Parameters:
| Model | YG-600 | YG-800 | YG-1000 | YG-1200 | YG-1400 | YG-1600 | YG-1900 | YG-2200 | YG-2600 |
| Power | 4-15*2 kw | 4-22*2kw | 4-30*2kw | 4-37*2kw | 4-45*2kw | 4-75*2KW | 4-90*2kw | 4-132*2kw | 4-160*2kw |
| Spindle Model | 18-20r/min | 18-35r/min | 18-35r/min | 18-35r/min | 14-35r/min | 14-25r/min | 14-25r/min | 16-25r/min | 16-25r/min |
| Capacity | 2-3t/h | 3-5t/h | 5-8t/h | 6-10t/h | 8-12t/h | 12-18t/h | 16-22t/h | 20-26t/h | 25-60t/h |
| Broken Size | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm | 3-10cm |
| Hopper Size | 820*900mm | 900*1000mm | 1200*1000mm | 1400*1000mm | 2000*2000mm | 2300*2000mm | 2300*2000mm | 2500*1800mm | 2425*1400mm |
| Dimensions | 2600*2000*1900mm | 2800*2000*1900mm | 3000*2000*1900mm | 3200*2000*1900mm | 4000*1700*2400mm | 5000*3000*2400mm | 6000*3500*2400mm | 7000*4000*4500mm | 8200*4000*4300mm |
5 Features of Industrial Scrap Shredder
This dual-shaft shredder equipment integrates multiple structural and control optimizations to support reliable long-term operation across diverse waste types.
- Heavy-duty reinforced frame: The outer body uses precision-machined extra-thick steel plates with a combined structure, paired with high-torque hexagonal rotating shafts. This build absorbs strong impact from bulky hard scrap and maintains structural stability even when processing mixed waste with varying hardness levels.
- Large-caliber heavy-duty feed hopper: The wide solid feeding opening accepts large bulk raw materials directly, including whole tires, large plastic crates, metal barrels and long wooden boards. This removes most pre-cutting work and speeds up overall waste processing workflows.
- Thick alloy moving blades: All cutting tools are forged from special alloy steel with high wear resistance and impact toughness. Thick blade bodies deliver strong shearing force and maintain sharp edges longer than standard thin blades, reducing maintenance frequency for multi-material processing.
- PLC intelligent protection system: The built-in PLC control unit supports automatic operation with start, stop and manual reverse functions. When overloaded by oversized or excessively fed materials, the system triggers automatic reverse to release pressure and protect core components from damage.
- Low-speed high-torque eco-friendly operation: Running at low rotation speed with high torque output, the unit produces low operational noise and controls dust dispersion within acceptable ranges, meeting on-site environmental requirements for indoor and outdoor waste processing facilities.
Application Scenarios for Industrial Scrap Shredder
- Scrap metal recycling yards: Process mixed light‑metal scraps, end‑of‑life vehicle shells and thin metal profiles. Reduce material volume and produce uniform fragments for convenient storage, transport and resale.
- Manufacturing workshops: Shred metal trimmings and production offcuts generated from metal fabrication. Streamline workshop waste management and free up valuable floor space.
- Mixed‑waste recycling facilities: Handle composite waste embedded with metal fragments. Prepare shredded feedstock for downstream sorting and further recovery workflows.
- Demolition job sites: Crush metal‑rich demolition debris. Support on‑site material treatment to facilitate waste reuse.
- Custom‑layout processing sites: Works well for fixed indoor plant installation, and adapts to flexible field‑based processing requirements for different operation layouts.
Multi-Material Blade Material Matching Strategy
For an industrial scrap shredder that processes multiple waste types, blade material selection directly determines service life, shredding quality and long-term operational stability. Different waste types place different demands on blade hardness, impact resistance and wear resistance, so one-size-fits-all blade configuration rarely delivers optimal results.
For soft, flexible waste such as rubber, fiber, paper and thin plastic films, 9CrSi alloy tool steel delivers cost-effective performance. This material features high hardness and good wear resistance, and maintains sharp cutting edges for light-duty continuous processing. It is the most economical choice for facilities that primarily process soft industrial waste with occasional small metal pieces.
For medium-hard waste including wooden pallets, discarded furniture, hard plastic blocks and thin metal sheets, Cr12MoV cold work die steel balances wear resistance and impact toughness. It withstands moderate impact from mixed hard-soft waste streams without chipping easily, making it the standard configuration for most general-purpose recycling operations.
For heavy hard scrap processing, operators should select SKD‑11 or premium Cr12MoV grades for heavy hard scrap processing, particularly when the unit primarily functions as a scrap steel shredder handling thick metal parts, steel barrels and structural steel offcuts. These materials deliver exceptional impact resistance and abrasion performance under continuous heavy metal shredding loads, greatly extending blade replacement cycles.
Blade thickness and tooth count are also customized based on target discharge size. Blade thickness sets the width of final shredded pieces, while fragment length is determined by blade circumference divided by the number of cutting teeth. All blades are custom-sized to fit exact chamber dimensions for tight shearing clearance and consistent 3- 10 cm output across different material types.
Industrial Scrap Shredder For Sale
Investing in a versatile industrial scrap shredder reduces the need for multiple dedicated crushing units and simplifies mixed waste processing workflows for recycling yards and industrial facilities. Whether you need a general-purpose unit for diverse waste streams or a heavy-duty scrap steel shredder for high-volume metal recycling, our 9-model lineup covers most common processing scales and material types.
If you are looking for a reliable scrap metal shredder machine to upgrade your waste processing line, or need help selecting the right blade configuration and model size for your specific waste mix, share your dominant material types, feed dimensions and required throughput with our team. We will provide professional model recommendations and detailed technical specifications tailored to your operational requirements.
