An electric floor crane, also known as a ground crane or electric ground crane, is a lightweight lifting device powered by electricity, with a base directly installed (or moved) on the ground, requiring no structural support. Its rated lifting capacity is typically 0.5-5 tons. Employing a cantilever or telescopic boom structure, it allows for 360° rotation or directional telescopic lifting. It combines electric lifting, precise control, and safety and stability, making it suitable for material handling and equipment hoisting in confined spaces such as workshops, warehouses, factories, and repair shops. It is a core lightweight lifting equipment for modern industry, offering high efficiency, environmental friendliness, and safety. If you are interested in electric floor cranes, please contact us for the best quote.
Electric Floor Crane Parameter
| 10Tons Electric Crane | |
| Model | YG-25 |
| Span | 25M |
| High | 8M |
| Lifting Equipment | |
| Model | YG-MD10T-8 |
| Lifting capacity | 10tons |
| Lifting height | <12M |
| Lifting speed | 8(8/0.8)M/min |
| Running speed | 20(30)M/min |
| Rope diameter | 15.5 |
| Wire diameter | 0.7 |
| Structure type | D-6*37+1 |
| I-beam track model | 32b-63c |
| Minimum radius of circular orbit | <3.5M |
| Lifting motor model | ZD41-4、ZDS0.8/7.5 |
| Power | 13KW 1.5/13Kw |
| Speed | 1380 |
| Voltage | 380V,3 phases |
| Current | 18A 2.4/18A |
| Running motor model | ZDY21-4 |
| Power | 2.4*2KW |
| Speed | 1380 |
| Voltage | 380V,3 phases |
| Current | 2.4A |
Main Types of Electric Ground-Mounted Cranes
- Fixed-Column Electric Ground-Mounted Cranes: With a base fixed to the ground and a 360° rotating cantilever design, these cranes offer structural stability and high load-bearing capacity. Suitable for fixed workstations and long-term stationary lifting, they are the mainstream model in workshops.
- Mobile Folding Electric Ground-Mounted Cranes: Equipped with casters/electric wheels, these cranes feature a foldable cantilever, eliminating the need for fixed installation. They can be flexibly moved to different workstations, occupying little space and offering convenient relocation, making them suitable for multi-area mobile operations.
- Fully Electric Self-Propelled Electric Ground-Mounted Cranes: Featuring a built-in drive system, these cranes offer wireless remote control for walking, lifting, and rotating. No manual pushing is required, resulting in a high degree of automation. Suitable for large-area warehousing and logistics loading/unloading scenarios.
Core Advantages of Electric Floor-Mounted Cranes
1. Green and Environmentally Friendly
Purely electric drive, zero exhaust emissions, low-noise operation, perfectly suited for workshops with stringent environmental requirements such as food, pharmaceutical, and electronics industries. Unlike diesel-powered equipment, there are no pollution concerns.
2. High Space Utilization
Compact design; the fixed model occupies only 1-2 square meters, while the mobile model is foldable for storage. No need for rail installation or occupying overhead space, solving the pain points of complex installation and large footprint of large overhead cranes and bridge cranes. Suitable for confined spaces such as narrow workshops, basements, and small warehouses.
3. High Efficiency and Labor Saving
Standard configuration includes wireless remote control + hand handle dual operation. Variable frequency speed control enables smooth start and stop of lifting and rotation. Lifting accuracy reaches ±3cm, avoiding material collision damage. One person can complete all operations, making it more than 10 times more efficient than manual handling, significantly reducing labor costs.
4. Safe and Reliable
Equipped with multiple safety systems, including overload protector, lifting limit switch, emergency stop, outrigger balance monitoring, and fault self-diagnosis, providing real-time warnings of potential hazards; high-strength steel body (Q345B), compliant welding process, structurally resistant to deformation and fatigue, ensuring strong long-term stability.
5. Easy Installation and Simple Maintenance
The fixed model only requires ground expansion bolts for fixing and can be installed in one day; the mobile model is ready to use out of the box, requiring no foundation construction. Modular design ensures high versatility of core components; daily maintenance only requires periodic lubrication and checking of hydraulic oil and electrical circuits, resulting in maintenance costs far lower than large lifting equipment.
6. Multifunctional and Reusable
Can be equipped with vacuum suction cups, electromagnetic suction cups, clamps, lifting clamps, and other accessories, suitable for lifting various materials such as steel, glass, molds, pipes, and equipment; one machine can replace multiple single-function devices, resulting in lower total life-cycle costs.
Frequently Asked Questions about Electric Floor-Mounted Cranes
1. How to choose between fixed-column and mobile folding electric floor-mounted cranes?
A: The key is the operating mode: Fixed-column cranes are suitable for long-term fixed-point lifting at a single workstation, offering the strongest stability and lower cost; mobile folding cranes are suitable for multi-workstation mobile operations, requiring no installation and offering flexible relocation. Choose the fixed model if the site is fixed and for long-term operations; choose the mobile model for multi-area operations.
2. What are the key parameters to consider when purchasing an electric floor-mounted crane?
A: Focus on 5 key aspects: ① Rated lifting capacity (with a 10%-15% safety margin); ② Maximum lifting height/cantilever length (suitable for the operating range); ③ Power type (220V household/380V industrial); ④ Mobility (fixed/mobile/self-propelled); ⑤ Safety features (overload protection, limit switches, emergency stop).
3. What are the after-sales guarantees for YG electric floor-mounted cranes?
A: As a professional manufacturer of electric floor cranes, YG offers a 1-year free warranty, lifetime cost-price spare parts, nationwide 24-hour technical support, and free operation training; vulnerable parts are shipped within 48 hours, ensuring worry-free after-sales service for floor cranes and electric ground cranes.
4. Can electric floor cranes be used outdoors?
1. A: Yes. YG electric floor cranes have an IP54 waterproof and dustproof rating, suitable for outdoor operation in sunny weather; it is recommended to avoid heavy rain and snow. For long-term outdoor use, a custom rain cover can be customized to prevent electrical circuits from getting damp.
5. What are the key points of daily maintenance?
A: ① Check the hydraulic oil level weekly and replace the hydraulic oil and filter every six months; ② Lubricate the slewing and telescopic components monthly; ③ Charge the battery regularly to avoid storing it with a dead charge; ④ Check the boom, hook, and wire rope after each operation and replace worn parts promptly.
Choose YG for Peace of Mind
The core logic for purchasing Electric Floor Cranes is “scenario suitability + brand reliability + safety compliance + optimal cost.” Choosing a professional electric floor crane manufacturer is key to ensuring equipment quality, after-sales service, and long-term use. YG, as a seasoned brand in the industry, offers a full range of products, including floor cranes and mini crawler cranes. Manufactured in strict accordance with GB/T 3811 and GB 6067 national standards, our products hold official CE certification. Boasting transparent parameter specifications and stable operating performance, they cover full tonnage ranges from 0.5 to 5 tons. Far exceeding peer alternatives in overall cost performance, these models come with highly competitive pricing. Widely exported to global markets such as Thailand, Vietnam, Malaysia, Singapore, the Philippines, Canada, and Russia, our equipment enjoys strong international recognition.
Contact us now for more details!
