A dry ice pellet making machine turns liquid carbon dioxide into compact cylindrical dry ice pellets through hydraulic extrusion. Companies that regularly consume dry ice eliminate reliance on external suppliers by producing pellets on location. Operators can freely adjust pellet dimensions to match diverse industrial tasks. Many service providers pair this equipment with dry ice blasting units to build a fully independent on-site cleaning workflow. Compared with purchasing prefabricated dry ice, on-demand production cuts waste caused by natural sublimation during storage and transportation.
Dry Ice Pellet Making Machine Technical Parameters:
| Equipment Model | YG30 | YG50 | YG100 | YG200 |
| Equipment capacity (kg/hour) | ≤30 | ≤50 | ≤100 | ≤170 |
| Motor power (kilowatts) | 3 | 4 | 5.5 | 7.5 |
| Hydraulic oil tank capacity (liters) | 20 | 50 | 80 | 80 |
| Net weight of equipment (kg) | 108 | 185 | 252 | 320 |
| Weight including wooden crate packaging (kg) | 127 | 218 | 305 | 375 |
| Equipment floor space (square meters) | 0.37m² | 0.51m² | 0.74m² | |
| Equipment dimensions (mm) | 780*480*580/1280 | 880*580*1280 | 1080*680*1320 | |
| Packaging box dimensions (mm) | 950*600*760/1450 | 1030*730*1450 | 1230*830*1480 | |
| Packaged volume (CBM) | 0.4 / 0.74 CBM | 1.1 CBM | 1.52 CBM | |
| Voltage requirements | Two-phase 220V / Three-phase 380V | Three-phase 380V AC power | ||
| System pressure | ≤160 Bar | ≤180 Bar | ||
| Granulation range | Default is 16mm (options: 3, 6, 9, 13, 16, 19mm) | |||
| Granulation density | ≤1550kg/m³ | |||
| Carbon dioxide pressure requirements | 12-22 Bar ≥66ppm | |||
| Carbon dioxide consumption | ≥75L /hr | ≥125L / hr | ≥250L / hr | ≥420L / hr |
| Power consumption per hour | ≥4 kWh | ≥5 kWh | ≥7 kWh | ≥9 kWh |
| Operating method | 7-inch color touchscreen & PLC programmable operating system & automated production | |||
| Operating Language | customized | |||
Features of YG Dry Ice Pellet Making Machine
1. Interchangeable Integrated Precision Mould
This dry ice pellet maker adopts thickened one-piece moulds with precision-bored ice outlet holes. Continuous long-hour operation brings minimal wear, and the mould maintains its shape without deformation to guarantee stable production results. Multiple mould specifications are available, covering 3mm, 6mm, 9mm, 16mm and 19mm sizes. Operators can swap moulds easily to manufacture pellets of different diameters to meet varied project demands.
2. Reinforced 316 Stainless Steel Extrusion Cylinder
The extrusion cylinder is constructed from thickened 316 stainless steel. Its wall thickness is 50 percent greater than ordinary standard models on the market. The dry ice pellet machine fits stainless steel precision filter plugs, which deliver higher filtering accuracy and longer service life than conventional brass filters. The special structural layout captures more carbon dioxide snow inside the cylinder and effectively lifts the conversion rate of liquid carbon dioxide into solid dry ice pellets. Multiple filter plugs work together to sustain steady extrusion performance during continuous shifts.
3. Intelligent PLC Automated Operating System
All models come equipped with a 7-inch color touchscreen paired with a programmable PLC control system. Operators adjust production parameters directly on the intuitive display panel. The operating interface supports customized language settings to accommodate global operators. The system automatically stabilizes hydraulic pressure within a safe working range and protects core components during long-term continuous operation.
4. Complete Factory Standard Accessories
Every unit leaves the factory with all necessary auxiliary parts for immediate commissioning. The standard configuration includes a selected column mould base, 5-meter waterproof power cord, 3-meter high-pressure low-temperature stainless steel braided pipe, mould stopper, ice outlet elbow, high-pressure cryogenic ball valve, ice scraper and anti-freezing gloves. Buyers do not need to source extra spare components to start production once the machine arrives.
How To Select A Suitable Dry Ice Pellet Making Machine?
Purchasers should evaluate multiple practical factors before confirming a model to match equipment performance with daily operation requirements.
- Production capacity requirements: Choose models based on daily dry ice consumption. The YG30 handles small and medium batch demands, while the YG200 supports large-scale non-stop continuous production.
- Dry ice pellet specifications: Confirm the pellet size required by your downstream equipment or projects. The YG series offers flexible mould choices to output customized pellet dimensions.
- Workplace space limits: The YG30 only occupies 0.37 square meters of floor space, making it ideal for workshops with limited area. Heavy-duty models like YG200 require more operating space for installation and maintenance.
- Power supply conditions: The dry ice pellet maker supports 220V single-phase power and 380V three-phase power options. Select the matching voltage according to the existing power supply at your facility.
- Automation expectations: The built-in touchscreen and PLC system enable automatic production and convenient parameter adjustment, lowering the learning barrier for new operators.
FAQs About Dry Ice Pellet Making Machine
A: The machine requires a liquid carbon dioxide storage tank, a single-phase or three-phase power supply, flat ground for installation, and cooling water sources for certain models.
A: Yes. The YG series supports replaceable moulds, offering multiple specifications including 3mm, 6mm, 9mm, 13mm, 16mm and 19mm to fit different usage scenarios.
A: The YG30 consumes approximately 4 kWh every hour, and the YG200 consumes roughly 9 kWh each hour. The equipment also consumes liquid carbon dioxide during production. Total energy consumption varies based on working capacity and local resource costs.
A: The control interface is simple and intuitive. Most operators can master standard operation after brief training.
A: The equipment fits dry ice cleaning service providers, mold manufacturers, auto component factories, food processing plants, cold chain logistics companies and all businesses with regular dry ice pellet consumption.
Dry Ice Pelletizer For Sale – YG Machinery
The YG series delivers four models with production capacities from 30 to 170 kg per hour. Every model produces dense (≤1550kg/m³), uniform pellets in sizes from 3mm to 19mm. The 316 stainless steel extruder cylinder is 50% thicker than standard units, providing longer service life and better pressure resistance. The one-piece precision mold maintains consistent pellet quality over years of use. All models feature a 7-inch color touchscreen with PLC programmable control, automated production, and customizable operating language. The complete standard configuration includes everything needed for immediate operation.
If you need a dry ice pellet machine that produces consistent, high-density pellets on demand, the YG series provides reliable, proven performance. Contact us with your production requirements—daily output, pellet size, and power configuration. We will recommend the right dry ice pellet maker for your operation. Get a free quote for your dry ice pelletizer for sale today.
