Hydraulic Metal Shear

The hydraulic metal shear, a core metal shearing attachment for excavators, is gradually replacing traditional dismantling tools due to its powerful shearing capabilities and flexible adaptability. It is a key component of scissor excavators and is widely used in building demolition, metal recycling, and scrap vehicle dismantling. When purchasing, it is essential to accurately match the operating scenario, excavator tonnage, and performance requirements, and to choose a reliable hydraulic metal shear manufacturer. For more information, please feel free to contact us.

Get a Free Quote

Hydraulic Metal Shear Parameter

Product	Excavator-mounted hydraulic demolition shear for waste scrap rebar
Item	YG-620	YG-1413	YG-2200	YG-2977	YG-4052
Weight kg	620	1413	2200	2977	4052
Max. Open Size mm	334.4	540	500	660	801
Width mm	864	1175	1370	1600	1700
Height mm	1521	2050	2380	2600	2700
Effective Shear Depth mm	286	348	486	578	736
Rotating Way	360 collision	360 hydraulic
Working Pressure Bar	235	300	320	320	320
Bottom Shear Force T	81.2	138.2	171.2	330.2	387.2
Medium Shear Force T	50.2	80.2	100.2	189.2	218.2
Tip Shear Force T	32.2	53.2	75.2	127.2	147.2
Applied Excavator Weight T	5-9	10-19	20-25	28-35	38-50

Get a Free Quote

Mainstream Types and Core Differences of Hydraulic Metal Shears

Hydraulic metal shears on the market can be divided into four main categories based on structure and function. Different types are suitable for different operating scenarios, making this the primary consideration when purchasing.

1. Eagle Beak Hydraulic Shear (Single-Cylinder Heavy-Duty Shear)

As the most commonly used excavator demolition shear, the eagle beak shear resembles an eagle’s beak in shape. It features a single large hydraulic cylinder, providing a strong shearing force. It is primarily used for dismantling heavy steel structures, scrap steel, and reinforced concrete. Its advantages include a compact structure, flexible operation, 360° rotation, and compatibility with 6-50-ton excavators. Suitable for factory demolition, scrap steel recycling, bridge dismantling, and other scenarios, it is the most versatile excavator hydraulic shear attachment.

2. Dual-Cylinder Hydraulic Shear (High-Pressure Shear)

Driven by dual parallel hydraulic cylinders, the shearing force is 30%-50% higher than that of a single-cylinder shear. It offers a larger opening and a more stable bite, primarily used for high-load operations such as thick steel plates, large-diameter rebar, heavy scrap steel, and ship dismantling. The disadvantages are its relatively large weight and compatibility with excavators of higher tonnage (over 20 tons). It is suitable for large scrap-metal processing plants and heavy demolition projects and is a professional-grade excavator metal shearing attachment.

3. Car Dismantling Shear (Scrap Car Dismantling Shear)

Optimized for scrap car dismantling, it features a narrow and long shear arm and a finely designed cutting edge, allowing for precise shearing of car beams, frames, and engine parts. Its efficiency is further enhanced when used with a car clamp. It features anti-material slippage and fine shearing characteristics, and is compatible with 12-30 ton excavators, making it an essential excavator demolition shear for car dismantling plants.

4. Concrete Breaker Shear (Multi-functional Shear)

Combining shearing and breaker functions, the jaw plate has breaker teeth, allowing simultaneous processing of reinforced concrete components, integrating the shearing of reinforcing steel and the breakering of concrete. Suitable for building demolition and old building renovation, it requires no attachment changes and is compatible with 15-40 ton excavators. It is a multi-functional excavator hydraulic shearing attachment.

Get a Free Quote

YG Hydraulic Metal Shears – Hot Selling Models

YG, a renowned manufacturer of excavator hydraulic shears, offers its Excavator Hydraulic Shears covering all tonnage and application scenarios. Below are four core hot-selling models with precise parameters and strong adaptability.

1. YG-620 (Miniature Eagle Beak Shear)

• Basic Parameters: Weight 620kg, suitable for 5-9 ton excavators; maximum opening 334.4mm; working pressure 235bar, cycle time 6 seconds.
• Core Configuration: Shear blade made of H13 wear-resistant steel (HRC58-60), 360° hydraulic rotation, quick-change interface, standard dustproof seal.
• Accessories: 1 spare shear blade, mounting bolts, hydraulic lines, maintenance tool kit.

2. YG-1413 (Medium-sized Dual-cylinder Shear)

• Basic Parameters: Weight 1413kg, compatible with 10-19 ton excavators; maximum opening 540mm; working pressure 300bar, cycle time 7 seconds.
• Core Configuration: Dual-cylinder drive, Hardox 500 wear-resistant steel shear body, modular shear blades (4 interchangeable sides), with overload protection.
• Accessories: Dual spare shear blades, hydraulic rotary motor, pin bushings, seal set.

3. YG-2200 (Heavy-duty Car Dismantling Shear)

• Basic Parameters: Weight 2200kg, compatible with 20-25 ton excavators; maximum opening 500mm; working pressure 320bar, cycle time 8 seconds.
• Core Configuration: Narrow and long shear arm design, anti-material jamming structure, 360° unlimited rotation, suitable for fine dismantling of scrapped vehicles.
• Accessories: Dedicated dismantling shear blades, truck bed adapter, hydraulic filter, maintenance manual.

4. YG-4052 (Extra Heavy Duty Shears)

• Basic Parameters: Weight 4052kg, compatible with 38-50 ton excavators; maximum opening 801mm; working pressure 320bar, cycle time 9 seconds.
• Core Configuration: Dual large hydraulic cylinders + hydraulic regeneration system, high-strength alloy steel body, suitable for heavy-duty scrap steel, ship, and bridge dismantling.
• Accessories: Heavy-duty spare shear blades, reinforced pins, high-pressure hydraulic lines, lifetime maintenance service.

Get a Free Quote

Key Considerations for Selecting Excavator Hydraulic Shears

1. Match the Excavator Tonnage: Pairing a small-tonnage excavator with a heavy-duty shear can easily damage the excavator; pairing a large-tonnage excavator with a light-duty shear is inefficient. Strictly adhere to the matching principle of “Excavator Tonnage → Hydraulic Shear Model”.
2. Focus on Materials and Workmanship: Prioritize Hardox 500 shear bodies, H13 shear blades, a hardness of HRC58 or higher, uniform welds, and adequate structural reinforcement.
3. Pay Attention to the Hydraulic System: Choose models with overload protection and hydraulic regeneration, with a cycle time ≤9 seconds and a stable pressure of 250-320 bar.
4. Choose the Right Manufacturer: Reputable hydraulic metal shear manufacturers provide warranties, spare parts supply, and after-sales maintenance, avoiding low-priced, inferior products. We recommend choosing the YG manufacturer.

Get a Free Quote

Choose a High-Quality Hydraulic Shear, Look for YG Manufacturer

Reliable hydraulic metal shear manufacturers (such as YG) not only provide a full range of excavator demolition shears and metal cutting accessories but also guarantee product quality, stable performance, and long-term after-sales support. Choosing high-quality hydraulic shears from YG manufacturer can increase work efficiency by 3-5 times, reduce long-term maintenance costs, and achieve efficient, safe, and stable demolition and cutting operations. Contact us now for product details and the latest pricing!
